Double-sided vhb Foam Tape

Double-sided vhb foam tape is closed cell, cross-linked polyethylene (PE) foam coated on both sides with a high-performance acrylic adhesive, and covered with releasing film or paper. The acrylic adhesive system is strong enough for outdoor applications due to its higher temperature, UV, weather, chemical and plasticizer resistance. Our foam tape is permanent and designed to have exceptional durability in demanding environments. Double-sided foam tape is suitable for applications where moisture resistance is required because of its good resistance to humidity, mild acids, oil and grease. VHB tape has excellent conformability and compressibility on wood, glass, cement, paper, plastic, metal surface. Double-sided vhb foam tape adheres well to textured and irregular surfaces. Our mounting tape can be easily die-cut. Based on the product structure and usage of double-sided vhb foam tape, it’s also called two-sided tape, poster tape, foam glazing tape, double face tape, two-way tape, outdoor double-sided tape, double sided wall tape and both sided tape etc.

Double-sided vhb foam tape applications:

  • Used for mounting nameplates, signs, small die cast parts, mirrors, maps, etc.
  • Used for sound and vibration dampening in business machines, industrial equipment, electronic component packaging and glass panel mounts, seals, gaskets, etc.

Double-sided vhb foam tape Details:

Thickness 0.3 mm to 12 mm
PE foam density 34-167 kgs/m2 or custom
Jumbo Roll Width 1040 mm, 1240 mm
Jumbo Roll Length 1 m to 300 m or custom
Log Roll Size custom
Foam Colors black, white, grey ,green, red, blue, grey etc.
Releasing Liner film/paper           colors: red, green, blue, white, yellow, etc.
Paper Core size 76 mm, 38 mm available

Double-sided vhb foam tape TDS (For 1.0 mm,PE Foam Tape):

Description Test result Unit Test method
Total thickness 1±0.005 mm GB/T 7125-1999
Density of backing 67 g/m /
Initial tack <150 cm GB/T 4852-2002
Peel adhesion >12 N/25 mm GB/T 2792-1998
Holding power >24 hrs GB/T 4851-1998
Temperature range -20∼120 /

Double-sided vhb foam tape structure:

double sided foam tape
